Alarm System
Release time：2016-04-21 08:48:48 viewed：2995
These cables are designed for installation in signaling and alarm systems. They allow the connection of contacts, detectors and seasons, infra-red as well as microwave of mixed technology systems, to the switchboard.
Fire Alarm Cable
Specifications
Fire Alarm Cable
Specifications
| S/NO: | Specification | Conductor | Insulation | Ground | Fire Resistance | Shield | Jecket |
| HK-FI-001 | 2*0.2mm² | 0.5mm | 1.6mFr-PVC/Silicone | 0.4mm | Mica Tape | AL | 4.8mm Fr-PVC/LSZH |
| HK-FI-002 | 2*0.5mm² | 0.8mm | 2.0mmFr-PVC/Silicone | 0.4mm | Mica Tape | AL | 5.6mm Fr-PVC/LSZH |
| HK-FI-003 | 2*0.75mm² | 0.97mm | 2.2mmFr-PVC/Silicone | 0.4mm | Mica Tape | AL | 6.0mm Fr-PVC/LSZH |
| HK-FI-004 | 2*1.0mm² | 1.15mm | 2.4mmFr-PVC/Silicone | 0.4mm | Mica Tape | AL | 6.4mm Fr-PVC/LSZH |
| HK-FI-005 | 2*1.5mm² | 1.38mm | 2.8mmFr-PVC/Silicone | 0.4mm | Mica Tape | AL | 7.2mm Fr-PVC/LSZH |
| HK-FI-006 | 2*2*0.2mm² | 0.5mm | 1.6mmFr-PVC/Silicone | 0.4mm | Mica Tape | AL | 5.6mm Fr-PVC/LSZH |
| HK-FI-007 | 2*2*0.5mm² | 0.8mm | 2.0mmFr-PVC/Silicone | 0.4mm | Mica Tape | AL | 6.6mm Fr-PVC/LSZH |
| HK-FI-008 | 2*2*0.75mm² | 0.97mm | 2.2mmFr-PVC/Silicone | 0.4mm | Mica Tape | AL | 7.2mm Fr-PVC/LSZH |
| HK-FI-009 | 2*2*1.0mm² | 1.15mm | 2.4mmFr-PVC/Silicone | 0.4mm | Mica Tape | AL | 7.6mm Fr-PVC/LSZH |
| HK-FI-010 | 2*2*1.5mm² | 1.38mm | 2.8mmFr-PVC/Silicone | 0.4mm | Mica Tape | AL | 8.5mm Fr-PVC/LSZH |
| HK-FI-011 | 2*2*0.2mm² | 0.5mm | 1.6mmFr-PVC/Silicone | 0.4mm | Mica Tape | AL | 4.8*8.0mm Fr-PVC/LSZH |
| HK-FI-012 | 2*2*0.5mm² | 0.8mm | 2.0mmFr-PVC/Silicone | 0.4mm | Mica Tape | AL | 5.6*9.6mm Fr-PVC/LSZH |
| HK-FI-013 | 2*2*0.75mm² | 0.97mm | 2.2mmFr-PVC/Silicone | 0.4mm | Mica Tape | AL | 6.0*10.5mm Fr-PVC/LSZH |
| HK-FI-014 | 2*2*1.0mm² | 1.15mm | 2.4mmFr-PVC/Silicone | 0.4mm | Mica Tape | AL | 6.4*11.4mm Fr-PVC/LSZH |
| HK-FI-015 | 2*2*1.5mm² | 1.38mm | 2.8mmFr-PVC/Silicone | 0.4mm | Mica Tape | AL | 7.2*13.0mm Fr-PVC/LSZH |
Specifications
| Model | Specification | Conductor | Insulation | Ground | Shield | Jacket |
| HK-FA-01 | 2Cx0.22mm2 | CU/TCU/CCA/TCCA | 1.0mmPVC | - | - | 3.2mm PVC/LSOH |
| HK-FA-02 | 4Cx0.22mm2 | CU/TCU/CCA/TCCA | 1.0mmPVC | - | - | 3.6mm PVC/LSOH |
| HK-FA-03 | 6Cx0.22mm2 | CU/TCU/CCA/TCCA | 1.0mmPVC | - | - | 4.1mm PVC/LSOH |
| HK-FA-04 | 8Cx0.22mm2 | CU/TCU/CCA/TCCA | 1.0mmPVC | - | - | 4.5mm PVC/LSOH |
| HK-FA-05 | 10Cx0.22mm2 | CU/TCU/CCA/TCCA | 1.0mmPVC | - | - | 5.2mm PVC/LSOH |
| HK-FA-06 | 12Cx0.22mm2 | CU/TCU/CCA/TCCA | 1.0mmPVC | - | - | 5.5mm PVC/LSOH |
| HK-FA-07 | 2Cx0.22mm2 | CU/TCU/CCA/TCCA | 1.0mmPVC | - | AL | 3.2mm PVC/LSOH |
| HK-FA-08 | 4Cx0.22mm2 | CU/TCU/CCA/TCCA | 1.0mmPVC | - | AL | 3.6mm PVC/LSOH |
| HK-FA-09 | 6Cx0.22mm2 | CU/TCU/CCA/TCCA | 1.0mmPVC | - | AL | 4.1mm PVC/LSOH |
| HK-FA-10 | 8Cx0.22mm2 | CU/TCU/CCA/TCCA | 1.0mmPVC | - | AL | 4.5mm PVC/LSOH |
| HK-FA-11 | 10Cx0.22mm2 | CU/TCU/CCA/TCCA | 1.0mmPVC | - | AL | 5.2mm PVC/LSOH |
| HK-FA-12 | 12Cx0.22mm2 | CU/TCU/CCA/TCCA | 1.0mmPVC | - | AL | 5.5mm PVC/LSOH |
| HK-FA-13 | 2Cx0.22mm2 | CU/TCU/CCA/TCCA | 1.0mmPVC | 7/0.2mm | AL | 3.3mm PVC/LSOH |
| HK-FA-14 | 4Cx0.22mm2 | CU/TCU/CCA/TCCA | 1.0mmPVC | 7/0.2mm | AL | 3.8mm PVC/LSOH |
| HK-FA-15 | 6Cx0.22mm2 | CU/TCU/CCA/TCCA | 1.0mmPVC | 7/0.2mm | AL | 4.2mm PVC/LSOH |
| HK-FA-16 | 8Cx0.22mm2 | CU/TCU/CCA/TCCA | 1.0mmPVC | 7/0.2mm | AL | 4.6mm PVC/LSOH |
| HK-FA-17 | 10Cx0.22mm2 | CU/TCU/CCA/TCCA | 1.0mmPVC | 7/0.2mm | AL | 5.3mm PVC/LSOH |
| HK-FA-18 | 12Cx0.22mm2 | CU/TCU/CCA/TCCA | 1.0mmPVC | 7/0.2mm | AL | 5.6mm PVC/LSOH |
| HK-FA-19 | 2Cx0.22mm2 | CU/TCU/CCA/TCCA | 1.0mmPVC | 7/0.2mm | AL+96/0.12 | 3.8mm PVC/LSOH |
| HK-FA-20 | 4Cx0.22mm2 | CU/TCU/CCA/TCCA | 1.0mmPVC | 7/0.2mm | AL+128/0.12 | 4.0mm PVC/LSOH |
| HK-FA-21 | 6Cx0.22mm2 | CU/TCU/CCA/TCCA | 1.0mmPVC | 7/0.2mm | AL+128/0.12 | 4.6mm PVC/LSOH |
| HK-FA-22 | 8Cx0.22mm2 | CU/TCU/CCA/TCCA | 1.0mmPVC | 7/0.2mm | AL+144/0.12 | 5.0mm PVC/LSOH |
| HK-FA-23 | 10Cx0.22mm2 | CU/TCU/CCA/TCCA | 1.0mmPVC | 7/0.2mm | AL+144/0.12 | 5.8mm PVC/LSOH |
| HK-FA-24 | 12Cx0.22mm2 | CU/TCU/CCA/TCCA | 1.0mmPVC | 7/0.2mm | AL+160/0.12 | 6.5mm PVC/LSOH |
